Standard colours:
| Lifting capacity, up to | 5,500 kg |
| Stroke length | 1,900 mm |
| Working height | 2,040 - 2,070 mm |
| Lifting / lowering time | ~ 55 sec. |
| Voltage | 3x230/400 V-50Hz - 35/25A |
| Motor | 2 x 2.8 kW |
| Total height post | 2908 mm |
| Total height incl. portal | 4,910- 5,270 mm |
| Drive-through width | 2,800 - 3,000 mm |
| Min. height | 140 mm |
| Width between posts | 3,185 - 3,385 mm |
| Total width - outer edges base plates | 3,910 - 4,110 mm |
| Total width - outer edges posts | 3560 - 3760 mm |
| Arm length, min. - max. | 957 - 1,900 mm |
